Honeywell – CSNV500M-151 Unipower CP Current Sensor 500A, 500K,

MPN: CSNV500M-151 · Brand: Honeywell

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Industrial Sensors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can CSNV500M-151 be shipped?

CSNV500M-151 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CSNV500M-151 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CSNV500M-151 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CSNV500M-151, subject to availability and destination.

Part of Honeywell's CSNV500 Series Closed Loop Current Sensor range. Honeywell patented technology to bring an enhanced combination of performance and reliability. They are non-intrusive and electrically isolated from the monitored circuit. This can ensure a simple and reliable structure without loss of power to the monitored circuit.The CSNV500 Series are rated for a primary current measurement range of ±500 A dc. They are calibrated and temperature compensated for improved accuracy using multi-point temperature characterization.

FEATURES

Active closed loop current sensing using Hall-effect technology

Utilizes proprietary Honeywell technology for temperature compensation

High accuracy and low temperature drift

Operating temperature of -40°C to 85°C [-40°F to 185°F]

Digital output: CAN bus output with selectable ID

Internal diagnostic function

Different configuration options: Mounting type, baud rate, CAN ID

UL, CE, and UKCA certifications; REACH and RoHS compliant DIFFERENTIATION

Accuracy: Multi-point temperature characterization and calibration for improved accuracy over temperature range

Magnetic immunity: Closed loop configuration and optimized magnetic circuit allow for enhanced performance in diverse magnetic environments

Flexible: Customizable on-board firmware to meet specific application requirements VALUE TO CUSTOMERS

Accurate: Designed to enable precise battery state measurement for improved user experience

Ease of use: Magnetic immunity allows for easy integration into different magnetic environments

Easy system integration: CAN communication is transmitted using international road vehicle standard ISO 11898. CAN 2.0A is the default protocol APPLICATIONS

Current measurement for battery management systems in electrified vehicles (EV, HEV, PHEV, BEV)

Current leakage detection and fault isolation in charging systems

Current measurement in energy storage systems

Fault detection in heavy industrial equipmentDistributor Inventory

Honeywell CSNV500M-151 — Unipower CP Current Sensor 500A, 500K, (CSNV500 Series Closed Loop Current Sensor). PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
