Honeywell – 72592D 72592D Systevo Corridor Lamp (SCL)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Honeywell Nurse Call Systems |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 72592D be shipped?
72592D is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 72592D in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 72592D and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 72592D, subject to availability and destination.
Part Number: 72592D
Systevo corridor lamp to indicate the status in the resident/patient room or duty room according to the VDE 0834 nurse call standards.
4 light segments with RGB-LEDs using the pre-defined color white, red, green an yellow. Alternative color selections possible, after software update and activation by corresponding software license.
Separate frontcover in color white or silver required. Option: nameplate.
Connection to the overriding multifunctional room unit via the data bus (DBUS) or in compatibility mode to the control outputs PR1/2, CL, CLWC.
Includes an user-friendly installation technology with color-coded connection terminals for each individual device and control functions, for a more efficient cabling and for an optimized commissioning process.
Upgradable to future system firmware thanks to advanced flash storage technologies. Includes the option for automated software update during operation.
A multi-level security concept enables local call signaling in the case of a lack of communication with the central unit of the system. Support of the cyber security requirements of modern data bus infrastructures.
System functions subject to license are provided by corresponding software licenses.
Features
Special material properties:
High quality plastic compound with antimicrobial surface for reduction of microorganisms and to inhibiting the growth of germs.
Good mechanical properties with high resistance to the daily stress (operation, cleaning, disinfection, shocks etc.).
Suitable for use in care facilities with high Requirements for hygiene, stability, Longevity and durability.
Plastic compound (PC + ABS-FR)
UV-resistant, halogen free
Antimicrobial surface, matt finish
Impact and heat resistance
Strength, longevity, durability
Flame protection (fire prot class V0)
Accessories
72590L1 Frontcover for SEM/SCL (silver) Systevo Call Ackermann
72590L2 Frontcover for SEM/SCL (white) Systevo Call Ackermann
72590T1 Systevo Nameplate (silver) Systevo Call Ackermann
72590T2 Systevo Nameplate (white) Systevo Call Ackermann
Honeywell 72592D — Systevo corridor lamp to indicate the status in the resident/patient room or duty room according to the VDE 0834 nurse call standards. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
Operating Characteristics
| Air Humidity | < 20% |
| Storage Temperature | -20 to 70°C |
| Minimum storage temperature (°C) | -20 |
| Minimum ambient temperature (°C) | 5° |
| Ambient Temperature | 5 to 40°C |
Dimensions & Weight
| Weight (g) | 100 |
| Dimensions | W: 110 mm H: 118 mm D: 27 mm |
Standards & Certifications
| Type Of Protection | Fire Protection Class (V0), IP20 |
Electrical Specifications
| Operating voltage (A) | 24 VDC +/-10 % |
Technical Specifications
| Mounting | Flush |
| Audio Output | PR1/2 CL CLWC |
Material Specifications
| Material | PC + ABS-FR |
Features
| Features & Benefits | Antimicrobial Surface with Matt Finish, Durability, Halogen Free, Impact and Heat Resistance, Longevity, Strength, UV-Resistant |
| Color | White (RAL9016) |
| Coating Type | Anti-Microbial Substance |
Others
| Industry | Healthcare |
