Home / Honeywell / Honeywell Fire Alarm Panels & Modules / 006820U 6820U ULTRA SERIES

Available on request

Honeywell – 006820U 6820U ULTRA SERIES

MPN: 006820U · Brand: Honeywell

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Honeywell Fire Alarm Panels & Modules
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 006820U be shipped?

006820U is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 006820U in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 006820U and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 006820U, subject to availability and destination.

The 6820U is the latest intelligent addressable FACP (Fire Alarm Control Panels) from Silent Knight and is a direct replacement for the 6820/5820XL FACP. The FACP has one built-in SLC (signaling line circuit), which can support 159 System Sensor® SK detectors and 159 SK modules, or 127 Hochiki® SD protocol devices. Additional SLC loops can be added for a maximum of 1110 (SK) or 635 (SD) points per panel

Features & Benefits:

Complies with UL 864 10th Edition and UL 2572 2nd Edition Standards

Expandable SLC loops to 1110 (SK) or 635 (SD) point capacity

Eight Flexput circuits for NAC outputs or auxiliary power

Selectable strobe synchronization for Amseco®, System Sensor, Wheelock®, and Gentex® devices

Built-in DACT with IP and optional cellular reporting

Built-in USB interface for quick and easy programming

JumpStart® auto programming reduces installation time

999 software zones and 999 output groups for flexible design options

23 preset notification cadence patterns (including ANSI® 3.41)

Allows up to 24 SBUS devices

Four programmable function keys

Two programmable relays and one fixed trouble relay

Compatible with SWIFT® wireless devices

Convenient field-upgradeable firmware

Common Communications Link for up to 17 sites

Network card allows copper network connection with a multi-mode or singlemode fiber connection

Real-time clock/calendar with automatic daylight savings control

History file with 1,000 event capacity

Available in a red cabinet

Surface mounting or flush mounting cabinet

Honeywell Silent Knight 006820U — The 6820U features an expandable SLC circuit, six Flexput circuits, dual-line DACT, powerful software features, and connectivity for up to 17 panels. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
