Danfoss FTP556F

Cplng, FLO-TEMP SERIES MALE, BRASS

MPN: FTP556F
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FTP556F?

Danfoss Cplng, FLO-TEMP SERIES MALE, BRASS, manufacturer part number FTP556F. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146030610
Angle shape	Straight
Body size	1/2
Brand	Danfoss
Burst pressure min bar	55
Burst pressure min psi	800
Connection style	Manual connect
End size 2	-8
End Type 1	Male push to connect
End Type 2	Female pipe (NPTF)
Flow rate GPM	13.00
Flow rate LPM	49.21
Fluid compatibility	Gas, Oil, Water
Hex size 1 IN	1.130
Hex size 1 MM	28.702
Item type	Male half
Latch type	Push/pull
Product length in	1.780
Product material	Brass
Seal material	Nitrile (NBR)
Sub brand	Hansen
Valve type	Straight thru
Working pressure max psi	200
Working pressure max BAR	14.00
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40

FTP556F: frequently asked questions

When can FTP556F be shipped?

FTP556F is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FTP556F in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FTP556F and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FTP556F, subject to availability and destination.
