Danfoss FC5936-0404S

Ftng (perm) SAE 37 thermo 595-16H-005

MPN: FC5936-0404S
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss FC5936-0404S?

Danfoss Ftng (perm) SAE 37 thermo 595-16H-005-, manufacturer part number FC5936-0404S. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Angle shape	45 Degree
Brand	Danfoss
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Compatible hoses	FC370
Construction Style	Crimp
Drop dimension IN	0.000
Drop dimension MM	8.00
End size 1	-4
End type 1	Female 37 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	0.563
Hex size 1 MM	14.288
Hose cut off factor IN	1.290
Hose cut off factor MM	32.766
Hose size	-4
Inside diameter IN	0.150
Inside diameter MM	3.810
Product material	Carbon steel
Thread sealant	Yes

FC5936-0404S: frequently asked questions

When can FC5936-0404S be shipped?

FC5936-0404S is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FC5936-0404S in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FC5936-0404S and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FC5936-0404S, subject to availability and destination.
