Danfoss B1T11BS

COUPLING,ST,M,1/8,B,-2BSP,NBR

MPN: B1T11BS
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss B1T11BS?

Danfoss COUPLING,ST,M,1/8,B,-2BSP,NBR, manufacturer part number B1T11BS. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146158819
Angle shape	Straight
Application	Chemical, Fluid transfer, Food and beverage, Injection moulding, Marine, Medical, Pressure washing, Steam cleaning
Body size	1/8
Burst pressure min bar	772
Burst pressure min psi	11200
Connection style	Manual connect
End size 1	-2
End size 2	-2
End Type 1	Male push to connect
End Type 2	Female BSPP swivel
Flow rate GPM	2.70
Flow rate LPM	10.22
Fluid compatibility	Versatile fluid
Hex size 1 IN	0.560
Hex size 1 MM	14.224
Item type	Male half
Latch type	Push/pull
Product length in	0.970
Product material	Brass
Safety locking mechanism	None
Seal material	Nitrile (NBR)
Thread size 1	G 1/8
Thread size 2	G 1/8
Valve type	Straight thru
Working pressure max psi	2800
Working pressure max BAR	193.00
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
