Danfoss 90208-085400-0

FTG:STEEL: F-JIC STRT WAS 3902-08548

MPN
90208-085400-0
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 90208-085400-0?

Danfoss FTG:STEEL: F-JIC STRT WAS 3902-08548, manufacturer part number 90208-085400-0. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Angle shapeStraight
BrandSynflex by Danfoss
Compatible hose ID IN0.500
Compatible hose ID MM12.700
Compatible hoses37AL
Compatible tube OD IN0.50
Compatible tube OD MM12.700
Construction StyleReusable
End size 1-12
End type 1Female 37 degree swivel
Hex size 1 IN0.880
Hex size 1 MM22.352
Hex size 2 IN0.940
Hex size 2 MM23.876
Hose cut off factor IN1.700
Hose cut off factor MM43.180
Hose size-8
Inside diameter IN0.390
Inside diameter MM9.906
Product materialCarbon steel
Thread sealantNo
Tube OD 1 IN0.500
Tube OD 1 MM12.700
Working pressure max BAR276
Working pressure max PSI4000

90208-085400-0: frequently asked questions

When can 90208-085400-0 be shipped?

90208-085400-0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 90208-085400-0 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 90208-085400-0 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 90208-085400-0, subject to availability and destination.
