Danfoss 84011927

SERVO PROPORTIONAL- SIZE 03, KBSD140300000092L24N11C07CON01H0010000000

MPN: 84011927
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 84011927?

Danfoss SERVO PROPORTIONAL- SIZE 03, KBSD140300000092L24N11C07CON01H0010000000, manufacturer part number 84011927. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Port flow LPM	24.00
A Port flow USGPM	6.30
Actuation	Solenoid operated single stage
Actuation Type	Solenoid controlled
B Port flow LPM	24.00
B Port flow USGPM	6.30
Brand	Vickers by Danfoss
Build orientation	Solenoid at B port end
Coil Rating & Overrides	24 VDC Amplifier supply, water-resistant overrides
Coil voltage	24 Volt DC
Command input	+/-10V Command +/- 10V feedback
Command Signal	+/- 10V Voltage
Communication protocol	CANopen
Configuration level	Directional level - 1
Design Series	01 Series
Digital Comm. Interface	CANOPEN
Electrical Connection	Electrical (PC7) 7 pin connector without plug
Electrical Connections	7 -PIN connector without plug, no enable
EN Series	Omit for standard
External Sensor	NONE
Feedback sensor	Yes
Fluid Cleanliness	17/15/12 micron
Fluid compatibility	Antiwear hydraulic oils and non alkyl-based Phosphate Esters
Interface	ISO4401-03/NFPA D03/CETOP 3/NG06
ISO Interface	ISO 4401 size-03
Manual override	None
Maximum pressure BAR	350
Maximum pressure PSI	5000
Model	Industrial proportional valves
Model Code 1	KBSD140300000092L24N11C07CON01
Model Code 2	H0010000000
Monitor Output	±10V Voltage feedback signal
On board electronics	Yes
Performance	Servo
Pilot Supply & Drain Option	None_
ProFX compatible	Yes
Reducer module	No
Reverse flow check	No
Seal type	Viton
Software Version	Software version -001
Special features	None
Spool Type	ISO4401-10/NFPA D10/CETOP 10/NG32
Stage	Single stage
Symmetric flow	Yes
Tank port rating BAR	250
Tank port rating PSI	3600
Valve Mount Type	Subplate
Valve type	AxisPro level 1
Valve Type	Proportional valve with integrated amplifier and electronic feedback
Working temp max C	70
Working temp max F	158
Working temp min C	-40
Working temp min F	-40

84011927: frequently asked questions

When can 84011927 be shipped?

84011927 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 84011927 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 84011927 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 84011927, subject to availability and destination.
