Danfoss 831AN00018A

F3-DG4V4-01-0BL-VM-KUP6- D2-G5-10, F3DG4V4010BLVMKUP6D2G510

MPN: 831AN00018A
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 831AN00018A?

Danfoss F3-DG4V4-01-0BL-VM-KUP6- D2-G5-10, F3DG4V4010BLVMKUP6D2G510, manufacturer part number 831AN00018A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Solenoid operated
Brand	Vickers by Danfoss
Coil Rating	12 VDC
Design Series	10 Series
Electrical Connection	Flying lead Deutsch connector
Energ Time	50-50 ms
Flow rate upto GPM	30.0
Flow rate upto LPM	115.0
Fluid Cleanliness	20/18/15 micron
Fluid compatibility	Petroleum oils
Indicator Light	No
Interface	ISO4401-05/NFPA D05
Manual override	Plain
Model Code 1	F3DG4V4010BLVMKUP6D2G510
Performance	Standard performance
Power Consumption	45 watt
Pressure rating BAR	315
Pressure rating PSI	4500
Product height in	4.310
Product length in	8.440
Product length mm	214.376
Product width in	2.840
Product width mm	72.136
Seal type	WATER GLYCOL
Solenoid Energising ID	Solenoid B at port B end
Special features	None
Spool Position Monitor	No
Spool Type	Spool 0
Spring Arrangement	Spring offset end to centre LH
Stage	Single stage
Surge Suppr Damper	Yes
Tank port rating BAR	120.0
Tank port rating PSI	1750
Valve Mount Type	Subplate/manifold mounted
Valve type	Directional control valve
Working temp max C	50
Working temp max F	122
Working temp min C	20
Working temp min F	70

831AN00018A: frequently asked questions

When can 831AN00018A be shipped?

831AN00018A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 831AN00018A in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 831AN00018A and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 831AN00018A, subject to availability and destination.
