Danfoss 83123792

GEAR PUMP GR2 FIXED DISPL

MPN: 83123792
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 83123792?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 83123792. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 25 cc
Drive gear	Spline DIN 5482 B17 x 14 L=10 ( rear tang 8 x 17,46 x L=6,5 ) (type 41)
Inlet size	1 GAS
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø36,5 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	3/4 GAS
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Main stage
Slash separator	Slash
Valve setting	without setting
