Danfoss 83097482

PUMP-VAR DISPL, CCW S45PVOC_J

MPN: 83097482
Category: Series 45 open-circuit axial piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 83097482?

Danfoss PUMP-VAR DISPL, CCW S45PVOC_J, manufacturer part number 83097482. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Frame	J frame axial piston open circuit pump
Rotation	Counter-clockwise rotation
Displacement and load life	65 cc/rev - Special servo piston - 260 bar maximum continuous rated pressure
Control type	Pressure compensated / load sensing, with electric dump valve solenoid-left, 12VDC NO, Deutsch [PC pressure range: 100-280 bar, LSpressure range: 10-40 bar]
Pressure compensator setting	210 bar [3045 psi]
Load sensing setting	20 bar [290 psi]
Torque limiter setting	Not applicable
Choke orifice	None
Gain orifice	Standard orifice
Shaft, auxiliary flange, and endcap	14 tooth 12/24 pitch shaft, SAE-B 13 tooth auxiliary, radial, inlet: 4-bolt split flange (2 inch port, 0.5 inch threads), outlet:4-bolt split flange (1 inch port, 0.375 inch threads), with displacement limiter
Shaft seal, front flange, and housing ports	Single Viton shaft seal, SAE-C 4-bolt flange, SAE O-ring ports
Displacement limiter	Adjustable displacement limiter set to max flow
Special hardware	Special hardware - none
Special features	Black paint, Danfoss tag
Proposition 65	Cancer and Reproductive Harm
