Home / Danfoss (Drives) / Manifold directional control valves / Danfoss 6040871-001
Danfoss (Drives)

Danfoss 6040871-001

DG4V-5-8CJ-VM-KUP5-G6-20, DG4V58CJVMKUP5G620

MPN
6040871-001
Price and lead time confirmed within 1 business day
Request a Quote

A real person replies, typically within 1 business day — see our privacy policy.

What happens next
  1. We check stock, condition and lead time
  2. You get a written quote by email
  3. Approve it and we ship — in-stock parts within 1 business day
  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • Ships via
  • 100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 6040871-001?

Danfoss DG4V-5-8CJ-VM-KUP5-G6-20, DG4V58CJVMKUP5G620, manufacturer part number 6040871-001. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypeSolenoid operated
BrandVickers by Danfoss
Coil Rating12 VDC
Design Series20 Series
Fluid Cleanliness19/17/14 micron
Fluid compatibilityPetroleum oils
InterfaceISO4401-05
Manual overridePlain
Model Code 1DG4V58CJVMKUP5G620
Pressure rating BAR315
Pressure rating PSI4500
Product height in4.450
Product length in12.680
Product length mm322.072
Product width in2.760
Product width mm70.104
Seal typeBuna-N
Solenoid Energising IDSol A port A/Sol B port B
Spool TypeSpool 8
Spring ArrangementSpring centred
StageSingle stage
Valve Mount TypeSubplate/manifold mounted
Valve typeDirectional control valve

6040871-001: frequently asked questions

When can 6040871-001 be shipped?

6040871-001 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 6040871-001 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 6040871-001 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6040871-001, subject to availability and destination.
