Home / Danfoss (Drives) / Lumi aluminum gear pumps / Danfoss 601AD00024C

Danfoss (Drives)

Danfoss 601AD00024C

GD5D1808AE20ARAPARAP05LA A6C

MPN: 601AD00024C
Category: Lumi aluminum gear pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 601AD00024C?

Danfoss GD5D1808AE20ARAPARAP05LA A6C, manufacturer part number 601AD00024C. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Design code	Third
Displacement- front	18.0 cm3/r [1.09 in3/r]
Displacement- rear	8.2 cm3/r [0.50 in3/r]
Identification	Itl
Inlet port- front	M6 x 1, 40.0 [1.57] pcd, dia 20.0 [0.79], german flanged port- 4 bolts
Inlet port- rear	M6 x 1, 40.0 [1.57] pcd, dia 20.0 [0.79], german flanged port- 4 bolts
Input shaft	11 teeth, 16/32 dp 30 deg involute spline, 20.0 [0.79] min full spline, 18.63 [0.73] dia, flat root side fit, shaft ext 38.5[1.51]
Mounitng	European rectangular 4 bolt, 50.0 [1.97] pilot dia. 9.0 [0.35] dia holes on 71.4 [2.81] x 96.1 [3.78] dist
Outlet port- front	M6 x 1, 35.0 [1.38] pcd, dia 15.0 [0.59], german flanged port- 4 bolts
Outlet port- rear	M6 x 1, 35.0 [1.38] pcd, dia 15.0 [0.59], german flanged port- 4 bolts
Paint	None
Product	External gear pump
Rotation	Left handed ccw
Size	Frame size
Special features	Option not available
Unit type	Double

601AD00024C: frequently asked questions

When can 601AD00024C be shipped?

601AD00024C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 601AD00024C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 601AD00024C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 601AD00024C, subject to availability and destination.
