Danfoss 4T6MR6

HOSE FTG, 4T/06, ORS-M/06, CS, STR

MPN: 4T6MR6
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T6MR6?

Danfoss HOSE FTG, 4T/06, ORS-M/06, CS, STR, manufacturer part number 4T6MR6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.200
A dimension MM	56.300
Angle shape	Straight
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.525
Construction Style	Crimp
End size 1	-6
End type 1	Male ORFS
Finish plating	Dura-Kote
Hex size 1 IN	0.748
Hex size 1 MM	19.000
Hose cut off factor IN	1.160
Hose cut off factor MM	29.300
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	0.984
Product height mm	25.000
Product length in	1.988
Product length mm	50.500
Product material	Carbon steel
Product width in	0.984
Product width mm	25.000 mm
Thread sealant	No
Thread size 1	11/16-16 UN
Working pressure max BAR	621
Working pressure max PSI	9100
