Danfoss 4T5DL3

HOSE FTG, 4T/03, DKOL/05, CS, STR

MPN: 4T5DL3
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T5DL3?

Danfoss HOSE FTG, 4T/03, DKOL/05, CS, STR, manufacturer part number 4T5DL3. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.560
A dimension MM	39.700
Angle shape	Straight
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.190
Compatible hose ID MM	4.760
Construction Style	Crimp
End size 1	-5
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.551
Hex size 1 MM	14.000
Hose cut off factor IN	0.870
Hose cut off factor MM	22.700
Hose size	-3
Inside diameter IN	0.100
Inside diameter MM	2.500
Product height in	0.708
Product height mm	18.000
Product length in	1.653
Product length mm	42.000
Product material	Carbon steel
Product width in	0.708
Product width mm	18.000 mm
Thread sealant	No
Thread size 1	M12x1.5
Working pressure max BAR	350
Working pressure max PSI	5100
