Danfoss 4T4FJB4

HOSE FTG, 4T/04, JIC-F/04, CS, 90D

MPN: 4T4FJB4
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T4FJB4?

Danfoss HOSE FTG, 4T/04, JIC-F/04, CS, 90D, manufacturer part number 4T4FJB4. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.810
A dimension MM	45.900
Angle shape	90 Degree
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Construction Style	Crimp
Drop dimension IN	0.680
Drop dimension MM	17.3
End size 1	-4
End type 1	Female 37 degree swivel
Finish plating	Zinc plating
Hex size 1 IN	0.551
Hex size 1 MM	14.0
Hose cut off factor IN	0.920
Hose cut off factor MM	23.300
Hose size	-4
Inside diameter IN	0.150
Inside diameter MM	3.700
Product height in	1.574
Product height mm	40.000
Product length in	2.165
Product length mm	55.000
Product material	Carbon steel
Product width in	0.787
Product width mm	20.000 mm
Thread sealant	No
Thread size 1	7/16-20 UNF
Working pressure max BAR	450
Working pressure max PSI	6550
