Danfoss 4T10DLB6

HOSE FTG, 4T/06, DKOL/10, CS, 90D

MPN: 4T10DLB6
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T10DLB6?

Danfoss HOSE FTG, 4T/06, DKOL/10, CS, 90D, manufacturer part number 4T10DLB6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.350
A dimension MM	59.700
Angle shape	90 Degree
Compatible hose ID IN	0.380
Compatible hose ID MM	9.525
Construction Style	Crimp
Drop dimension IN	1.350
Drop dimension MM	34.20
End size 1	-10
End type 1	24 deg. DKO swivel light duty
Finish plating	Protective oil
Hex size 1 IN	0.866
Hex size 1 MM	22.000
Hose cut off factor IN	1.360
Hose cut off factor MM	34.500
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	2.007
Product height mm	51.000
Product length in	2.637
Product length mm	67.000
Product material	Carbon steel
Product width in	0.984
Product width mm	25.000 mm
Seal material	Nitrile (NBR)
Thread sealant	No
Thread size 1	M18x1.5
Working pressure max BAR	250
Working pressure max PSI	3650
