Danfoss
407845Danfoss 407AA00002A
1GR60P4S RELIEF VALVE DIRECT ACTI, 1GR60-P-4-S-XXX
- MPN
- 407AA00002A
- Category
- Cartridge valves
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 407AA00002A?
Danfoss 1GR60P4S RELIEF VALVE DIRECT ACTI, 1GR60-P-4-S-XXX, manufacturer part number 407AA00002A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Adjustment type | Leakproof Screw |
| Brand | Danfoss |
| Cavity | CVA-20-01-0 |
| Factory set pressrue BAR | 22.500 |
| Flow rate LPM | 100.000 |
| Fluid compatibility | MIL-H-5606, SAE10, SAE20, etc |
| Function | Pressure Relief Valve |
| Housing | No |
| Installation type | Screw-in Cartridge |
| Leakage | 0.3 cc/min |
| Max working pressure BAR | 40.000 |
| Min working pressure BAR | 5.000 |
| Model Code 1 | 1GR60-P-4-S-XXX |
| Number of housing ports | 2 |
| Number of valve ports | 2 |
| Operating temperature | -40 C to 120 C (-40 to 248 F) |
| Port size | None |
| Port type | Cartridge Only |
| Pressure rating BAR | 40.000 |
| Product height in | 1.000 |
| Product height mm | 25.400 |
| Product length in | 3.270 |
| Product length mm | 83.058 |
| Product width in | 1.000 |
| Product width mm | 25.400 mm |
| Recommended filtration level | 18/16/13 |
| Seal type | Buna-N |
| Special features | None |
| Style | Spool |
407AA00002A: frequently asked questions
When can 407AA00002A be shipped?
407AA00002A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 407AA00002A in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 407AA00002A and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 407AA00002A, subject to availability and destination.
