Danfoss 406AA03201A

1CE120F35S3-SP200BAR/290 0PSI, 1CE120-F-35-S-3-200

MPN: 406AA03201A
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 406AA03201A?

Danfoss 1CE120F35S3-SP200BAR/290 0PSI, 1CE120-F-35-S-3-200, manufacturer part number 406AA03201A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Adjustment type	Screw
Brand	Danfoss
Cavity	A877
Flow rate LPM	120.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Overcenter Valve
Housing	No
Installation type	Screw-in Cartridge
Leakage	0.25 cc/min
Max load induced p BAR	270.000
Max pilot adjust p BAR	66.000
Max relief press BAR	350.000
Min pilot adjust p BAR	54.000
Model Code 1	1CE120-F-35-S-3-200
Number of housing ports	3
Number of valve ports	3
Operating temperature	-30 C to 90 C (-22 to 194 F)
Operation	Pilot operated
Pilot ratio	3.5:1
Port size	None
Port type	Cartridge Only
Pressure rating BAR	350.000
Product height in	1.500
Product height mm	38.100
Product length in	4.820
Product length mm	122.428
Product width in	1.500
Product width mm	38.100 mm
Recommended filtration level	18/16/13
Seal type	Nitrile
Style	Pilot assisted relief w check
