Danfoss 2HLRB143

Cplng, Socket 2-HKIL

MPN: 2HLRB143
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 2HLRB143?

Danfoss Cplng, Socket 2-HKIL, manufacturer part number 2HLRB143. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146198341
Air inclusion max cc	2.20
Air inclusion max in3	0.13
Angle shape	90 Degree
Body size	1/4
Brand	Danfoss
Burst pressure min bar	414
Burst pressure min psi	6000
Connection style	Manual connect
End type 1	Female Push to Connect
End type 2	Line/hose/tube
Flow rate GPM	2.20
Flow rate LPM	8.33
Fluid compatibility	Liquid and gases
Fluid loss cc	1.00000
Fluid loss in3	0.06100
Item type	Female half
Latch type	Push/pull
Product material	Stainless steel
Safety locking mechanism	None
Seal material	Fluorocarbon (FKM)
Sub brand	Hansen
Working pressure max psi	1500
Working pressure max BAR	103
Working temperature max C	200
Working temperature max F	392
Working temperature min C	-20
Working temperature min F	-4
