Danfoss 2609B

COUPLING,Auto-F,M,1/4,CS,-4BSPT,NBR

MPN: 2609B
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 2609B?

Danfoss COUPLING,Auto-F,M,1/4,CS,-4BSPT,NBR, manufacturer part number 2609B. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146099600
Angle shape	Straight
Body size	1/4
Burst pressure min bar	41
Burst pressure min psi	600
Compliances	A-A-59439
Connection style	Automatic connect
End size 1	-4
End size 2	-4
End type 1	Male push to connect
End type 2	Female pipe BSPT
Finish plating	Zinc
Flow rate GPM	209.22
Flow rate LPM	791.98
Fluid compatibility	Compressed air
Hex size 1 IN	0.690
Hex size 1 MM	17.526
Item type	Male half
Latch type	Push/pull
Product length in	1.520
Product material	Carbon steel
Safety locking mechanism	Pin lock
Seal material	Nitrile (NBR)
Thread size 1	R 1/4
Thread size 2	R 1/4
Working pressure max psi	150
Working pressure max BAR	10
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
