Danfoss 20411Y1-45-20TZN

HOSE NIPPLE ASSY,1P/20,DKOL/45,CS,STR

MPN
20411Y1-45-20TZN
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 20411Y1-45-20TZN?

Danfoss HOSE NIPPLE ASSY,1P/20,DKOL/45,CS,STR, manufacturer part number 20411Y1-45-20TZN. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

A dimension IN3.600
A dimension MM91.500
Angle shapeStraight
BrandWinner by Danfoss
Compatible hose ID IN1.250
Compatible hose ID MM31.800
Construction StyleCrimp
End Type 124 deg. DKO swivel light duty
Finish platingZinc nickel
Hex size 1 IN1.969
Hex size 1 MM50.000
Hose cut off factor IN1.470
Hose cut off factor MM37.500
Hose size-20
Inside diameter IN1.060
Inside diameter MM27.000
Product height in1.968
Product height mm50.000
Product length in3.602
Product length mm91.500
Product materialCarbon steel
Product width in1.968
Product width mm50
Thread sealantNo
Thread size 1M45x2
Tube OD 1 MM35.000
Working temperature max C100
Working temperature max F212
Working temperature min C-40
Working temperature min F-40

20411Y1-45-20TZN: frequently asked questions

When can 20411Y1-45-20TZN be shipped?

20411Y1-45-20TZN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 20411Y1-45-20TZN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 20411Y1-45-20TZN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 20411Y1-45-20TZN, subject to availability and destination.
