Danfoss 1SA16MJ16

HOSE NIPPLE ASSY,1W/16,JIC-M/16,CS,STR

MPN: 1SA16MJ16
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1SA16MJ16?

Danfoss HOSE NIPPLE ASSY,1W/16,JIC-M/16,CS,STR, manufacturer part number 1SA16MJ16. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	3.250
A dimension MM	82.540
Angle shape	Straight
Compatible hose ID IN	1.000
Compatible hose ID MM	25.400
Construction Style	Crimp
End size 1	-16
End Type 1	Male 37 degree
Finish plating	Dura-Kote
Hex size 1 IN	1.380
Hex size 1 MM	35.052
Hex size 2 MM	34.000
Hose cut off factor IN	1.900
Hose cut off factor MM	48.260
Hose size	-16
Inside diameter IN	0.820
Inside diameter MM	20.828
Product height in	1.380
Product height mm	35.052
Product length in	3.250
Product length mm	82.550
Product material	Carbon steel
Product width in	1.380
Product width mm	35.052
Series	1SA
Thread sealant	No
Thread size 1	1 5/16-12 UN
Working pressure max BAR	241
Working pressure max PSI	3500
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
