Danfoss 1SA16FJ16

HOSE NIPPLE ASSY,1W/16,JIC-F/16,CS,STR

MPN: 1SA16FJ16
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1SA16FJ16?

Danfoss HOSE NIPPLE ASSY,1W/16,JIC-F/16,CS,STR, manufacturer part number 1SA16FJ16. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146133342
A dimension IN	3.287
A dimension MM	83.500
Angle shape	Straight
Compatible hose ID IN	1.000
Compatible hose ID MM	25.400
Construction Style	Crimp
End connection torque	108-113 lb-ft(148-154 Nm)
End size 1	-16
End Type 1	Female 37 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	1.250
Hex size 1 MM	38.000
Hex size 2 MM	34.925
Hose cut off factor IN	1.933
Hose cut off factor MM	49.100
Hose size	-16
Inside diameter IN	0.814
Inside diameter MM	20.700
Product height in	1.000
Product height mm	25.400
Product length in	3.290
Product length mm	83.566
Product material	Carbon steel
Product width in	1.000
Product width mm	25.4
Series	1SA
Thread size 1	1 5/16-12 UN
Working pressure max BAR	280
Working pressure max PSI	4050
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
