Danfoss 1G8DL4

HOSE FTG, 1G/04, DKOL/08, CS, STR

MPN: 1G8DL4
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1G8DL4?

Danfoss HOSE FTG, 1G/04, DKOL/08, CS, STR, manufacturer part number 1G8DL4. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.890
A dimension MM	48.200
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.250
Compatible hose ID MM	6.400
Compatible hoses	GH585, GH586
Construction Style	Crimp
End size 1	-8
End Type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.748
Hex size 1 MM	18.999
Hose cut off factor IN	0.970
Hose cut off factor MM	24.800
Hose size	-4
Inside diameter IN	0.160
Inside diameter MM	4.200
Product height in	0.748
Product height mm	18.999
Product length in	1.897
Product length mm	48.184
Product material	Carbon steel
Product width in	0.748
Product width mm	18.999
Proposition 65	Cancer and Reproductive Harm
Series	OTC
Thread sealant	No
Thread size 1	M16x1.5
Working pressure max BAR	275.00
Working pressure max PSI	4000.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40

1G8DL4: frequently asked questions

When can 1G8DL4 be shipped?

1G8DL4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1G8DL4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1G8DL4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1G8DL4, subject to availability and destination.
