Danfoss 1B8FL8

HOSE NIPPLE ASSY, 4S/08, C61/08, CS, STR

MPN: 1B8FL8
Category: Spiral hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1B8FL8?

Danfoss HOSE NIPPLE ASSY, 4S/08, C61/08, CS, STR, manufacturer part number 1B8FL8. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146130051
A dimension IN	3.130
A dimension MM	79.500
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Compatible hoses	FC616, FC659, FC736, GH493, 2661 (Size dependent), FC136, FC318 (Size dependent), FC636
Compatible tube OD IN	0.50
Compatible tube OD MM	12.700
Construction Style	Crimp
End connection torque	15-19 lb-ft(20-25 Nm)
End size 1	-8
End type 1	Split flange code 61
Finish plating	Zinc plating
Hose cut off factor IN	2.060
Hose cut off factor MM	52.300
Hose size	-8
Inside diameter IN	0.380
Inside diameter MM	9.600
Product height in	1.335
Product height mm	33.909
Product length in	3.230
Product length mm	82.042
Product material	Carbon steel
Product width in	1.335
Product width mm	33.909 mm
Series	B Series
Thread sealant	No
Tube OD 1 IN	0.500
Tube OD 1 MM	12.700
Working pressure max BAR	345
Working pressure max PSI	5000
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
