Danfoss 1AA12MP10

HOSE FTG, 1A/10, NPTF-M/12, CS, STR

MPN: 1AA12MP10
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1AA12MP10?

Danfoss HOSE FTG, 1A/10, NPTF-M/12, CS, STR, manufacturer part number 1AA12MP10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146125774
A dimension IN	2.430
A dimension MM	61.700
Angle shape	Straight
Compatible hose ID IN	0.620
Compatible hose ID MM	15.900
Construction Style	Crimp
End size 1	-12
End Type 1	Male pipe (NPTF)
Finish plating	Zinc plating
Hex size 2 MM	27.000
Hose cut off factor IN	1.400
Hose cut off factor MM	35.600
Hose size	-10
Inside diameter IN	0.500
Inside diameter MM	12.800
Product height in	1.390
Product height mm	35.306
Product length in	2.560
Product length mm	65.024
Product material	Carbon steel
Product width in	1.390
Product width mm	35.306
Series	1A/Z Series
Thread size 1	3/4-14 NPTF
Working pressure max BAR	345
Working pressure max PSI	5000
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
