Danfoss 1A8EK6

HOSE FTG, 1A/06, DKH-M/08, CS, STR

MPN: 1A8EK6
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A8EK6?

Danfoss HOSE FTG, 1A/06, DKH-M/08, CS, STR, manufacturer part number 1A8EK6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146124920
A dimension IN	1.980
A dimension MM	50.300
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Construction Style	Crimp
End connection torque	52-66 lb-ft(70-90 Nm)
End size 1	-8
End Type 1	24 deg. tube port heavy duty
Finish plating	Dura-Kote
Hex size 1 IN	0.870
Hex size 1 MM	22.098
Hex size 2 MM	22.000
Hose cut off factor IN	0.980
Hose cut off factor MM	25.000
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	1.060
Product height mm	26.924
Product length in	1.980
Product length mm	50.292
Product material	Carbon steel
Product width in	1.067
Product width mm	27.101
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	M20x1.5
Working pressure max BAR	400.00
Working pressure max PSI	5800.00
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
