Danfoss 158-2768-001

MOTOR-ORBITAL,T SERIES 370 [22.6], MT0226CA16AB0000060000AB0AL00A

MPN
158-2768-001
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 158-2768-001?

Danfoss MOTOR-ORBITAL,T SERIES 370 [22.6], MT0226CA16AB0000060000AB0AL00A, manufacturer part number 158-2768-001. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Model CodeMT0226CA16AB0000060000AB0AL00A
Motor SeriesT Series
Valve systemSpool valve
Orbital gearwheel set typeGeroler
Motor size370
Geometric displacement [cm3/r [in3/r]]370 [22.6]
Motor typeStandard
Motor functionHigher efficiency and smooth running (Low speed valving)
Mounting flange type2 Bolt - A
Mounting flange dimension [pilot dia x height, bolt circle dia, hole [mm [inch]]]82.5 x 6.1, 106.4, 10.4 [3.25 x 0.24, 4.19, 0.41] SAE A
Shaft typeSplined
Shaft dimensionDia. 7/8 inch, 13T
Shaft Keyn/a
Main port thread typeNPT / NPTF
Main port styleSideport - aligned
Main port dimension1/2 - 14 NPTF
Drain Port DimensionNone
Brake Release Port Dimensionn/a
PaintedYes
Paint informationPrimer, Yellow
Special Features AssemblyStandard
Dust sealNo data available
Shaft SealNBR - Low pressure, Double shaft seal - Spec. Component
Seal Kit9900904-000
Front bearing typeJournal bearing
Rear bearing typeJournal bearing
Orbital gearwheel setStandard
Check valve functionNo
Hydraulic valve functionNone
SensorNone
PackagingNo data available
Name TagDanfoss name tag
Design code01
BrandDanfoss
Sub brandChar-Lynn

158-2768-001: frequently asked questions

When can 158-2768-001 be shipped?

158-2768-001 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 158-2768-001 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 158-2768-001 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 158-2768-001, subject to availability and destination.
