Danfoss 12211-16-16Z

HOSE NIPPLE ASSY,2P/16,BSPP-M/16,CS,STR

MPN: 12211-16-16Z
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12211-16-16Z?

Danfoss HOSE NIPPLE ASSY,2P/16,BSPP-M/16,CS,STR, manufacturer part number 12211-16-16Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	3.523
A dimension MM	89.500
Angle shape	Straight
Brand	Winner by Danfoss
Compatible hose ID IN	1.000
Compatible hose ID MM	25.400
Construction Style	Reusable
End size 2	-16
End Type 1	Male ORB BSPP
End Type 2	Line/hose/tube
Finish plating	Zinc plating
Hex size 1 IN	1.614
Hex size 1 MM	41.000
Hose cut off factor IN	1.673
Hose cut off factor MM	42.500
Hose size	-16
Inside diameter IN	0.826
Inside diameter MM	21.000
Product height in	1.862
Product height mm	47.300
Product length in	3.523
Product length mm	89.500
Product material	Carbon steel
Product width in	1.614
Product width mm	41
Series	Winner 2-Piece
Thread sealant	No
Thread size 1	G 1
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
