Danfoss 11344335

V10HS01P02PB001B00ZAR000AZ31, V10HS01P02PB001B00ZAR000AZ31

MPN: 11344335
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11344335?

Danfoss V10HS01P02PB001B00ZAR000AZ31, V10HS01P02PB001B00ZAR000AZ31, manufacturer part number 11344335. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Seal type	NBR Seals
PUMP TYPE	VANE PUMP
Series	High Pressure
Cover type	STANDARD COVER
Mounting type	2 BOLT FLANGE SAE-A SIZE
INLET PORT TYPE	1" NPT THREAD
RING CAPACITY	2 GPM
OUTLET PORT TYPE	COVER STANDARD - .500 NPT THREAD, F COVER- PRESSURE PORT-.750-16 UN-2B ,TANK PORT -.500 NPT
SHAFT SEAL AND BEARING	SINGLE LIP SEAL&SEALED BEARING
Shaft type	STRAIGHT KEY - 3/16,MAJOR DIA-0.75, EXTENSION-1.75
OUTLET COVER PORT ORIENTATION	90°CCW FROM INLET PORT
FLOW RATE THRU ORF IN COVER	No Flow
PRESSURE SETTING	NO PRESSURE SETTING
DESIGN CODE	31 Design
Shaft rotation	RH CW ROTATION VIEWED FROM SHAFT END
SPECIAL FEATURE SUFFIX	No special feature
Brand	Vickers by Danfoss
Model Code 1	V10HS01P02PB001B00ZAR000AZ31

11344335: frequently asked questions

When can 11344335 be shipped?

11344335 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11344335 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11344335 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11344335, subject to availability and destination.
