EVHC-ACTUATOR-DT-24V-A
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Compensated directional control valves |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 11162298 be shipped?
11162298 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11162298 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11162298 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11162298, subject to availability and destination.
Danfoss EVHC-ACTUATOR-DT-24V-A, manufacturer part number 11162298. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A Port Placement | N/A |
| B Port Placement | N/A |
| CAN Protocol | N/A |
| Certification | N/A |
| Coil Power | 30 W |
| Connector Direction | 180 (Outwards) |
| Connector Type | 2x2 Deutsch - DT04 |
| Control Signal | PWM |
| De-Stroke Reaction A | 300 ms |
| De-Stroke Reaction B | 300 ms |
| Digital Type | N/A |
| Disable Function | N/A |
| Ex Application | N/A |
| Extra Function | N/A |
| Fault Reaction & Recovery | N/A |
| Float Direction | A Port |
| Hysteresis | 15.0% |
| IP Rating | IP67 |
| Length | 110 |
| Manual Override | N/A |
| Marking | N/A |
| Max Oil Consump. Steady State | 0 l/min |
| Max Oil Consumption | 0 l/min |
| Maximum System Pressure Peaks | 65 |
| Minimum Float Position | 7.8 |
| Nominel A Stroke | 7 |
| Nominel B Stroke | 7 |
| On-Stroke Response A | 300 ms |
| On-Stroke Response B | 300 ms |
| Output Signal | N/A |
| Outward Side Interface | N/A |
| Pilot Pressure | 23 (PVHC) |
| Pilot Pressure Full Stroke | 23.0 bar |
| Pilot Pressure Neutral | 3.5 bar |
| Port Connection Type | N/A |
| Port Size | N/A |
| Primer | N/A |
| Product Category | Standard Part |
| Product type | N/A |
| Proposition 65 | Cancer and Reproductive Harm |
| PVDI connector coding | N/A |
| Resolution | 250 |
| Valve Side Interface | EVHC O-Ring |
| Voltage | 24 |
