Danfoss 11162297

EVHC-ACTUATOR-DT-12V-A

MPN: 11162297
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11162297?

Danfoss EVHC-ACTUATOR-DT-12V-A, manufacturer part number 11162297. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Port Placement	N/A
B Port Placement	N/A
CAN Protocol	N/A
Certification	N/A
Coil Power	30 W
Connector Direction	180 (Outwards)
Connector Type	2x2 Deutsch - DT04
Control Signal	PWM
De-Stroke Reaction A	300 ms
De-Stroke Reaction B	300 ms
Digital Type	N/A
Disable Function	N/A
Ex Application	N/A
Extra Function	N/A
Fault Reaction & Recovery	N/A
Float Direction	A Port
Hysteresis	15.0%
IP Rating	IP67
Length	110
Manual Override	N/A
Marking	N/A
Max Oil Consump. Steady State	0 l/min
Max Oil Consumption	0 l/min
Maximum System Pressure Peaks	65
Minimum Float Position	7.8
Nominel A Stroke	7
Nominel B Stroke	7
On-Stroke Response A	300 ms
On-Stroke Response B	300 ms
Output Signal	N/A
Outward Side Interface	N/A
Pilot Pressure	23 (PVHC)
Pilot Pressure Full Stroke	23.0 bar
Pilot Pressure Neutral	3.5 bar
Port Connection Type	N/A
Port Size	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
PVDI connector coding	N/A
Resolution	250
Valve Side Interface	EVHC O-Ring
Voltage	12
