Danfoss 11100134

PROT.GEAR MOTOR GR2 FAN DRIVE WITH VALVE

MPN: 11100134
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11100134?

Danfoss PROT.GEAR MOTOR GR2 FAN DRIVE WITH VALVE, manufacturer part number 11100134. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 8,0 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 CO01
E_VALVE GROUP2	DCV+PVLP+PRV Valve (Reversin
F_DRAIN GROUP2	Inlet on cover - Outlet on cover - drain on cover driven gear position
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	Without inlet
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover M+In-Out 7/8+DCV 12VD
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	Setting proportional valve, type of connector 12 DT Volt and pressure 90 bar with oil ISO VG68 a 40°-50°C
