Danfoss 11040166

GEAR PUMP GR2 FIXED DISPL

MPN: 11040166
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11040166?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11040166. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 14 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4/3,2 CO01 LBD
Inlet size	1-1/16-12UN
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø36,5 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Pump
Slash separator	Slash
Valve setting	without setting
