Danfoss (Drives)

Danfoss 11020253101

SM C6T DEVICE(XGMA)

MPN: 11020253101
Category: Track and swing drive piston motors

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11020253101?

Danfoss SM C6T DEVICE(XGMA), manufacturer part number 11020253101. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A_B main port size	BSPP 1/2
Anti-reverse valve and setting	None
Application	Excavator
Brand	Danfoss
Danfoss swing type	Danfoss Swing Motor
Design code	First version
Displacement	32 cm3/r (1.95 in3/r)
Flow rate GPM	9.40
Flow rate lpm	35.6
Gear ratio	19.5 two stage
Gearbox input shaft spec	None
Gearbox mounting with vehicle	None
Gearbox output shaft spec	None
Identification	Standard namplate
Maximum output speed RPM	57
Motor mounting	Standard
Motor shaft spec	Standard
Old model code	JMF032RR02030101019A00A
Output torque LBF-IN	19091.0
Output torque Nm	2157.0
Paint	Standard
Parking brake and setting	Standard
Product height in	8.700
Product height mm	220.980
Product length in	8.200
Product length mm	208.280
Product width in	10.700
Product width mm	271.78
Relief valve and setting	230bar (3335 psi) 40 lpm (10.56 gpm)
Special requirement	None
Timedelay and setting	4 bar (58 psi)
Working pressure bar	2626.0
Working pressure psi	38087

11020253101: frequently asked questions

When can 11020253101 be shipped?

11020253101 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11020253101 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11020253101 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11020253101, subject to availability and destination.
