Danfoss (Drives)

Danfoss 11020250201

SM C5T(43-05-19)Device

MPN: 11020250201
Category: Track and swing drive piston motors

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11020250201?

Danfoss SM C5T(43-05-19)Device, manufacturer part number 11020250201. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A_B main port size	BSPP 1/2
Anti-reverse valve and setting	None
Application	Excavator
Brand	Danfoss
Danfoss swing type	Danfoss Swing Motor
Design code	First version
Displacement	43 cm3/r (2.62 in3/r)
Flow rate GPM	21.79
Flow rate lpm	82.5
Gear ratio	19.5 two stage
Gearbox input shaft spec	None
Identification	Standard namplate
Maximum output speed RPM	99
Motor mounting	Standard
Motor shaft spec	Standard
Old model code	JMF043RR0211010111900A00A
Output torque LBF-IN	23104.8
Output torque Nm	2610.5
Paint	Primer + yellow
Parking brake and setting	Standard
Product height in	303.000
Product height mm	7696.200
Product length in	435.500
Product length mm	11061.700
Product width in	303.000
Product width mm	7696.2
Relief valve and setting	200bar (2987 psi) 40 lpm (10.56 gpm)
Special requirement	None
Timedelay and setting	5 bar (72 psi)
Working pressure bar	200.0
Working pressure psi	2901

11020250201: frequently asked questions

When can 11020250201 be shipped?

11020250201 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11020250201 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11020250201 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11020250201, subject to availability and destination.
