COUPLING,1000,F,1/4,B,-4MNPT

Name: COUPLING,1000,F,1/4,B,-4MNPT
Brand: Danfoss (Drives)
SKU: 1100

MPN: 1100 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Danfoss Hansen® quick disconnect couplings
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 1100 be shipped?

1100 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1100 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1100 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1100, subject to availability and destination.

Danfoss COUPLING,1000,F,1/4,B,-4MNPT, manufacturer part number 1100. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146156211
Angle shape	Straight
Body size	1/4
Burst pressure min bar	552
Burst pressure min psi	8000
Connection style	Manual connect
End size 1	-4
End size 2	-4
End type 1	Female pipe (NPTF)
End type 2	Line/hose/tube
Flow rate GPM	179.00
Flow rate LPM	677.59
Fluid compatibility	Compressed air, Gases and liquids
Hex size 1 IN	0.690
Hex size 1 MM	17.526
Item type	Female half
Product height in	1.000
Product height mm	25.400
Product length in	2.160
Product length mm	54.864
Product material	Brass
Product width in	1.000
Product width mm	25.400 mm
Seal material	Nitrile (NBR)
Thread size 1	1/4-18 NPTF
Working pressure max psi	2000
Working pressure max BAR	138
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
