Danfoss 10H41SL

CPLNG, HK SERIES FEMALE, SLEEVE LOCK

MPN: 10H41SL
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 10H41SL?

Danfoss CPLNG, HK SERIES FEMALE, SLEEVE LOCK, manufacturer part number 10H41SL. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146196637
Air inclusion max cc	48.00
Air inclusion max in3	2.93
Angle shape	Straight
Body size	1 1/4"
Brand	Danfoss
Certifications	ISO 7241-1 Series B
Connection style	Manual connect
End size 1	-20
End size 2	-20
End type 1	Female Push to Connect
End type 2	Female pipe (NPTF)
Finish plating	Zinc
Flow rate GPM	76.00
Flow rate LPM	287.69
Fluid compatibility	Hydraulic fluid
Fluid loss cc	48.00000
Fluid loss in3	2.92900
Hex size 1 IN	2.380
Hex size 1 MM	60.452
Item type	Female half
Latch type	Push/pull
Product material	Carbon steel
Safety locking mechanism	Sleeve lock
Seal material	Nitrile (NBR)
Sub brand	Hansen
Thread size 1	1 1/4-11 1/2 NPTF
Valve type	2 way
Working pressure max psi	2900
Working pressure max BAR	200
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
