Danfoss 06Z-106-200BX

HOSE FTG, 1Z/6, NPTF-M/6, -S

MPN: 06Z-106-200BX
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 06Z-106-200BX?

Danfoss HOSE FTG, 1Z/6, NPTF-M/6, -S, manufacturer part number 06Z-106-200BX. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	639789328861
A dimension IN	2.170
A dimension MM	55.000
Angle shape	Straight
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Compatible hoses	H881
Construction Style	Crimp
End size 1	-6
End type 1	Male pipe (NPTF)
Finish plating	Dura-Kote
Hex size 2 IN	0.688
Hex size 2 MM	17.000
Hose cut off factor IN	1.270
Hose cut off factor MM	32.200
Hose size	-6
Inside diameter IN	0.2600
Inside diameter MM	6.7000
Product height in	1.067
Product height mm	27.100
Product material	Carbon steel
Series	1A/Z Series
Thread sealant	Yes
Thread size 1	3/8-18 NPTF
Working pressure max BAR	552
Working pressure max PSI	8100
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
