Danfoss 04Z-685

Hose End (perm) 45 D F SAE 37 Swivel

MPN: 04Z-685
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 04Z-685?

Danfoss Hose End (perm) 45 D F SAE 37 Swivel, manufacturer part number 04Z-685. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	639789294371
Angle shape	45 Degree
Compatible hose ID IN	0.250
Compatible hose ID MM	6.350
Compliances	SAE J1176
Construction Style	Crimp
Drop dimension IN	0.370
Drop dimension MM	9.40
End size 1	-8
End type 1	Female 37 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	0.625
Hex size 1 MM	15.900
Hose cut off factor IN	1.120
Hose cut off factor MM	28.448
Hose size	-4
Inside diameter IN	0.1700
Inside diameter MM	4.3180
Product material	Carbon steel
Thread sealant	No
