Danfoss 02-137664-3

Industrial vane pump

MPN: 02-137664-3
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 02-137664-3?

Danfoss 45V60AF 86C22R, 45V60AF 86C22R, manufacturer part number 02-137664-3. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

DESIGN NO	DESIGN NO
IPM FRAME SIZE	45V Single Pump
OUTLET POST FRM CVR END	OUTLET INLINE WITH INLET
PORT CONNECTION	INLET: 4 BOLT FLANGE OUTLET: 4 BOLT FLANGE
PUMP TYPE	VANE PUMP
RING CAPACITY	60 GPM
SEALS TYPE	STANDARD SEAL
Series	SERIES DESIGNATION
SHAFT	86- 3/8 SQUARE KEY
BODY MOUNTING FLANGE	VICKERS STANDARD
PORT THREAD TYPE	INCH THREAD PORT CONNECTION
ROTATION FROM SHAFTEND	CLOCKWISE
MOUNTING	FOOT MOUNT
Model Code 1	45V60AF 86C22R

02-137664-3: frequently asked questions

When can 02-137664-3 be shipped?

02-137664-3 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 02-137664-3 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 02-137664-3 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-137664-3, subject to availability and destination.
