B&R 5CFXPR.240G-20

CFexpress 240 GB TLC

MPN: 5CFXPR.240G-20
Category: CFexpress cards

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare B&R parts? We buy surplus →

What is the B&R 5CFXPR.240G-20?

CFexpress 240 GB TLC

Specifications

General information

Continuous reading – Maximum	Rev. D0 and later: Up to 1,285 MB/s; Up to Rev. C0: Up to 1,615 MB/s
Continuous writing – Maximum	Rev. D0 and later: Up to 627 MB/s; Up to Rev. C0: Up to 702 MB/s
Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – CRA (Cyber Resilience Act)	In preparation
Certifications – UL	cULus E115267; Industrial control equipment
Certifications – DNV	Temperature: B (0 to 55°C); Humidity: B (up to 100%); Vibration: A (0.7 g); EMC: B (bridge and open deck)
Certifications – CCS	Yes
Capacity	240 GB
Data retention	10 years (note: Per JEDEC (JESD47), EOL conditions are not permitted to be reached before 18 months. A higher average daily write workload reduces the expected service life and data retention of the data storage medium.)
Data reliability	Max. 1 unrecoverable error per 10 16 bits read
Lifetime monitoring	Yes
MTBF	Rev. D0 and later: Min. 3,000,000 h; Rev. C0 and alter: Min. 2,000,000 h
Type	Type B
Supported operating modes	NVMe 1.3 (PCIe Gen3 x2)

Endurance

Data volume – Client workload	Rev. D0 and later: 471 TBW; Up to Rev. C0: 188 TBW (note: TBW = Terabytes written Client workload per JEDEC JESD219 standard.)
3D TLC flash memory	Yes
Wear leveling	Dynamic and static
Error-correcting code (ECC)	Yes
S.M.A.R.T. support	Yes
Storage health data support	Yes, starting with AR 6.00
Mating cycles	Up to 12,000

Support

Operating systems – Windows 11 IoT Enterprise LTSC 64-bit	Yes
Operating systems – Windows 10 IoT Enterprise LTSC 64-bit	Yes
Operating systems – Linux for B&R 12	Yes
Software – PVI	6.0
Hardware	APC4100, xPC3200, xPC2300

Electrical properties

Power consumption

Rev. D0 and later: Max. 2.15 W; Up to Rev. C0: Max. 2.40 W

Ambient conditions

Temperature – Operation	-40 to 85°C
Temperature – Storage	-40 to 85°C
Temperature – Transport	-40 to 85°C
Relative humidity – Operation	Up to 90% at 85°C for 96 h, non-condensing
Relative humidity – Storage	Up to 90% at 85°C for 96 h, non-condensing
Relative humidity – Transport	Up to 90% at 85°C for 96 h, non-condensing
Vibration – Storage	10 to 2,000 Hz: 20 g peak
Vibration – Transport	10 to 2,000 Hz: 20 g peak
Shock – Operation	500 g peak, 1 ms
Shock – Storage	500 g peak, 1 ms
Shock – Transport	500 g peak, 1 ms

Mechanical properties

Dimensions – Width	29.8 mm
Dimensions – Length	38.5 mm
Dimensions – Depth	3.8 mm
Weight	Approx. 10 g

Accessories

Optional accessories (1)

5ACCRCFX.240G-20

CFexpress cards — HMI CFexpress 240 GB TLC
