B&R 5AC801.HDDS-00
40 GB hard disk
- MPN
- 5AC801.HDDS-00
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 5AC801.HDDS-00?
40 GB hard disk
Slide-in
Specified for 24-hour operation
S.M.A.R.T. Support
This 40 GB hard disk is specified for 24-hour operation, features an extended temperature range and can be used in APC810 and PPC800 system units with a slide-in drive slot.
Specifications
General information
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – UL | cULus E115267; Industrial control equipment |
Hard disk
| Data transfer rate – Internal | Max. 450 Mbit/s |
| Data transfer rate – To/From host | Max. 150 MB/s (Ultra DMA mode 5) |
| Positioning time – Minimum (track to track) | 1 ms |
| Positioning time – Nominal (read access) | 12.5 ms |
| Positioning time – Maximum (read access) | 23 ms |
| Capacity | 40 GB |
| Number of heads | 1 |
| Number of sectors | 78,140,160 |
| Bytes per sector | 512 |
| Cache | 8 MB |
| Speed | 5400 rpm ±1% |
| Startup time | Typ. 3 s (from 0 rpm to read access) |
| MTBF | 750,000 POH (note: With 8760 POH (power-on hours) per year and 70°C surface temperature.) |
| S.M.A.R.T. support | Yes |
| Interface | SATA |
| Access time | 5.6 ms |
Ambient conditions
| Temperature – Operation | -30 to 85°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 20°C per hour.) |
| Temperature – 24-hour operation | -30 to 85°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 20°C per hour.) |
| Temperature – Storage | -40 to 95°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 20°C per hour.) |
| Temperature – Transport | -40 to 95°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 20°C per hour.) |
| Relative humidity – Operation | 5 to 90%, non-condensing (note: Humidity gradient: Maximum 15% per hour.) |
| Relative humidity – Storage | 5 to 95%, non-condensing (note: Humidity gradient: Maximum 15% per hour.) |
| Relative humidity – Transport | 5 to 95%, non-condensing (note: Humidity gradient: Maximum 15% per hour.) |
| Vibration – Operation | 5 to 500 Hz: 2 g, no unrecoverable errors |
| Vibration – Storage | 5 to 500 Hz: 5 g, no unrecoverable errors |
| Vibration – Transport | 5 to 500 Hz: 5 g, no unrecoverable errors |
| Shock – Operation | 300 g and 2 ms duration, no unrecoverable errors; 150 g and 11 ms duration, no unrecoverable errors |
| Shock – Storage | 800 g and 2 ms duration, no unrecoverable errors; 400 g and 0.5 ms duration, no unrecoverable errors |
| Shock – Transport | 800 g and 2 ms duration, no unrecoverable errors; 400 g and 0.5 ms duration, no unrecoverable errors |
| Elevation – Operation | -300 to 5000 m |
| Elevation – Storage | -300 to 12192 m |
Mechanical properties
| Dimensions – Width | 22 mm |
| Dimensions – Height | 172.5 mm |
| Dimensions – Depth | 150 mm |
| Installation | Permanent (note: Slide-in compact installation.) |
| Weight | 387 g |
Vendor information
| Manufacturer | Seagate |
| Manufacturer's product ID | ST940817SM |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
5AC801.HDDS-00: frequently asked questions
When can 5AC801.HDDS-00 be shipped?
5AC801.HDDS-00 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5AC801.HDDS-00 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5AC801.HDDS-00 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5AC801.HDDS-00, subject to availability and destination.
