B&R 1TGMPSAFETYX.00-01

Mapp Technology, software license

MPN: 1TGMPSAFETYX.00-01
Category: Technology Guard

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare B&R parts? We buy surplus →

What is the B&R 1TGMPSAFETYX.00-01?

User interface for VC4-based HMI applications

For up to 8 SafeBOOL or 8 SafeINT parameters

For single-choice or multiple-choice applications

Component mapp SafeOPTION or MpSafetyX provides secure data exchange between HMI elements and the SafeLOGIC controller. This makes it possible to transfer safety-related parameters from the HMI application to the safety application. Typical use cases include selecting an operating mode or defining limit or threshold values.

One "OptionManager" function block is supported per SafeLOGIC controller during configuration in Automation Studio. Up to 16 option function blocks can then be used per "OptionManager" function block. The following option function blocks are available:

MpSafetyXOptionIntUI: This function block can be used to configure up to 8 SafeBOOL parameters. Either "Multiple-choice" or "Single-choice" mode is possible.

MpSafetyXOptionBoolUI: This function block can be used to configure up to 8 SafeINT parameters.

Suitable function blocks for configuration in SafeDESIGNER are included in library "SafeOPTION_SF".

Specifications

Short description

mapp Technology

1TGMPSAFETYX.00-01 B&R software license

General information

System requirements – Automation Studio	4.2.5 or later
System requirements – Automation Runtime	F4.25 or later
System requirements – SafeDESIGNER	4.2.3 or later
System requirements – Safety Release	1.10 or later
Certifications – CRA (Cyber Resilience Act)	Not applicable
Certifications – Functional safety	IEC 61508, up to SIL 3 ; IEC 62061, up to SIL 3 ; ISO 13849-1, up to Cat. 4 / PL e ; IEC 61511, up to SIL 3
Single-user license	Runtime license
Alternative package license	mapp flat-rate 1TGMPFLAT.02
Behavior if license missing	Solid red LED indicates license violation
Diagnostics	Via Automation Studio (SDM, Logger, etc.)

Scope of software license

Properties and functions – Tracing variable values	No
Properties and functions – Dynamic variable assignment	No
Properties and functions – Recordings	No
Properties and functions – Data archival	None
Properties and functions – Data exchange	Secure data exchange between HMI elements and the SafeLOGIC controller over 2 communication channels.;
Properties and functions – Modular software concepts	Supported
Properties and functions – Web-based diagnostics	Yes
Properties and functions – XML configuration	Yes
Included library	MpSafetyX
Use cases	- Safe mode selector switch; - Safe limit value

Accessories

Required accessories (order separately)

0TG1000.02	Technology Guard — Technology Guard (HID)
0TG1000.01	Technology Guard — Technology Guard (MSD)

Downloads & documentation

Official documents from B&R, downloaded directly from the manufacturer.

Data sheets & manuals

Data sheet MpSafetyXPDF · 3 MB · 1.00 (06/14/2017) - EN
