COMMUNICATION MODULE S20-KNX-1

Name: COMMUNICATION MODULE S20-KNX-1
Brand: Bosch Rexroth
SKU: R911174966

MPN: R911174966 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Communicaton Modules
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can R911174966 be shipped?

R911174966 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R911174966 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R911174966 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R911174966, subject to availability and destination.

S20 in protection type IP20 is the flexibly scalable I/O system for shortest cycle times and highest precision and provides a real-time data flow between control and peripherals - whether locally at the XM control or as decentralized I/O station. Compact, modular and simple Space-saving I/O technology for top hat rail mounting Individually combinable modules Innovative assembly and installation concept

Specifications

Connection type	Push-in
Number of channels	1
Width [mm]	35
Height [mm]	54
Depth [mm]	126.1
International protection code	IP20
Transient protection	Suppressor diode
Transfer rate	9600 Baud
Overvoltage protection UL and UP	Electronic (35 V, 0.5 s)
Logic voltage UBus [V DC]	5
Conductor cross-section	AWG: 24 ... 16; Flexible: 0.2-1.5 mm²; rigid: 0.2-1.5 mm²
Inverse polarity protection (interface KNX)	Polarity protection diode
Permissible air humidity (storage) [%]	5-95
Permissible air humidity (transport) [%]	5-95
Ambient temperature (storage and transport) [°C]	-40-85
Ambient temperature (during operation) [°C]	-25-60
Air pressure (operation)	70-106 kPa (up to 3,000 m above sea level)
Air pressure (storage / transport)	70-106 kPa (up to 3,000 m above sea level)
Weight [kg]	0.17
