Bosch Rexroth R901570609

PROPORTIONAL DIRECTIONAL VALVE 4WRAE6W1-30-3X/VN9/24L1/B

MPN: R901570609
Category: Proportional directional valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R901570609?

Industrial hydraulic valve in a high performance range. Reliable control of the oil flow direction according to hydraulic symbol.

Spool valve

Direct actuated

With concealed auxiliary actuation

With digital on-board electronics and Bluetooth interface

Specifications

Connection diagram	ISO 4401-03-02-0-05
Product family	4WRA
Operating pressure, max. [bar]	350.0
Max. flow [l/min]	42.0
Spool symbol	Symbol W1
Type of connection	Subplate mounting
Nominal flow [l/min]	26.0
Size	6
Type of actuation	Electrical with on-board electronics
Number of ports	4
Number of switching positions	3
Supply voltage	24 VDC
Electrical connector	Connector, 5-pole, M12 x 1, coding A
Electrical connection description	Connector, 5-pole, M12 x 1, coding A according to EN 61076-2-101
Connectivity	Bluetooth; IO-Link
Conformity description	CE – Electromagnetic compatibility (EMC) directive 2014/30/EU; UKCA – Electromagnetic compatibility (EMC) SI2016/1091
Conformity	CE; UKCA
Hydraulic fluid	HDFR; HEES; HEPG; HETG; HFDU; HL; HLP; HLPD; HVLP; HVLPD
Seals	FKM
Weight [kg]	2.5
