Beckhoff ERI2809-0022
IO-Link box, 16-channel digital output, 24 V DC, 0.5 A, M12, zinc die-cast
- MPN
- ERI2809-0022
- Category
- Digital-Ausgang ERI2xxx
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Beckhoff ERI2809-0022?
The ERI2809-0022 IO-Link box with digital outputs connects the binary control signals from the controller on to the actuators at the process level. The 16 outputs handle load currents of up to 0.5 A each, although the sum current is limited to 4 A. This
Specifications
Specifications
| Communication | IO-Link |
| Interfaces | 1 x M12 plug, A-coded |
| Data transfer rates | 230.4 kbaud (COM 3) |
| Specification version | IO-Link V1.1, Class B |
| Number of outputs | 16 |
| Output connections | M12, screw type |
| Load type | ohmic, inductive, lamp load |
| Nominal output voltage | 24 V DC (-15%/+20%) |
| Max. output current | 0.5 A per channel, from P24, individually short-circuit proof, ∑ 4 A |
| Short-circuit current | typ. 1.5 A |
| Current consumption | typ. 100 mA from L+ |
| Auxiliary power current | typ. 20 mA + load |
| Electrical isolation | L+/P24: yes |
| Weight | approx. 450 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Dimensions (W x H x D) | 60 mm x 126 mm x 26.5 mm |
| Material | zinc die-cast |
| Installation | 2 fixing holes 3.5 mm diameter for M3; 2 fixing holes 4.5 mm diameter for M4 |
