Beckhoff – CX1100-0012 Power supply units and I/O interfaces for CX1030

Name: Beckhoff – CX1100-0012 Power supply units and I/O interfaces for CX1030
Brand: Beckhoff
SKU: CX1100-0012

MPN: CX1100-0012 · Brand: Beckhoff

Price on request

Discontinued by Beckhoff — we can still source the original CX1100-0012 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	IPC service products (discontinued)
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the CX1100-0012 now that it is discontinued?

Yes. Beckhoff has discontinued the CX1100-0012, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can CX1100-0012 be shipped?

CX1100-0012 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CX1100-0012 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CX1100-0012 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CX1100-0012, subject to availability and destination.

One of three power supply modules can be selected for CX1030 systems. The power supply of all other system components is ensured via the internal PC/104 bus; no separate supply lines are required. However, the CX1100 components offer further important

Beckhoff CX1100-0012 — Power supply units and I/O interfaces for CX1030. Beckhoff service-phase product: no longer in the current range. PartnerPLC sources discontinued and surplus Beckhoff automation parts — request a quote for price, condition and lead time.

Specifications

Technical data

Lifecycle	Service phase (discontinued, no longer in Beckhoff's product range)
Power supply	24 V DC (-15%/+20%)
Current supply E-bus	–
Current supply K-bus	up to max. 1.75 A
Connection type	spring-loaded technique (adapter terminal)
NOVRAM	8 kbytes
Display	FSTN display 2 lines x 16 characters of text, illuminated
Diagnostics LED	1 x PWR, 1 x I/O Run, 1 x I/O Err
Dimensions (W x H x D)	42 mm x 109 mm x 92 mm
Weight	approx. 240 g
Storage temperature	-25…+85°C
Operating temperature	0…55°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protection rating	IP20
