Beckhoff – CX1030-N031 System interfaces

MPN: CX1030-N031 · Brand: Beckhoff

Price on request

Discontinued by Beckhoff — we can still source the original CX1030-N031 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	IPC service products (discontinued)
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the CX1030-N031 now that it is discontinued?

Yes. Beckhoff has discontinued the CX1030-N031, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can CX1030-N031 be shipped?

CX1030-N031 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CX1030-N031 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CX1030-N031 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CX1030-N031, subject to availability and destination.

A number of optional interface modules are available for the basic CX1030 CPU module that can be installed ex factory. The system interfaces cannot be retrofitted or expanded in the field. They are supplied ex factory in the specified configuration and

Beckhoff CX1030-N031 — System interfaces. Beckhoff service-phase product: no longer in the current range. PartnerPLC sources discontinued and surplus Beckhoff automation parts — request a quote for price, condition and lead time.

Specifications

Technical data

Lifecycle	Service phase (discontinued, no longer in Beckhoff's product range)
Interfaces	1 x COM1 + 1 x COM2, RS422/RS485
Type of connection	2 x D-sub socket, 9-pin
Properties	max. baud rate 115 kbaud, not combinable with N030/N040
Power supply	via system bus (through CX1100-xxxx power supply modules)
Dimensions (W x H x D)	19 mm x 100 mm x 51 mm
Weight	approx. 80 g
Relative humidity	95%, no condensation
Operating/storage temperature	0…+55°C/-25…+85°C
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protection rating	IP20
